Modular rack platform for telecom and datacenter applications, designed for reliable cable management, efficient cooling and scalable deployment.
DATACON racks are engineered for modern telecom and data infrastructure where flexibility, structural precision and long-term operational reliability matter. The system supports modular configurations, efficient heat dissipation and rapid installation, making it suitable for datacenters, telecom nodes, 5G infrastructure and communication hubs.
✓
Modular and scalable design
Available in multiple dimensions and configurable variants for diverse telecom and datacenter deployments.
✓
Efficient thermal management
Optimized airflow and material combination support fast and effective heat dissipation without unnecessary complexity.
✓
Fast installation and service access
Designed for simple assembly, easier equipment integration and practical maintenance access in live infrastructure environments.
✓
Custom-ready construction
Supports customer-specific configurations, accessories and internal equipment layouts for project-specific requirements.
A modular rack solution for telecom and datacenter applications, focused on installation efficiency, flexible internal arrangement and dependable thermal performance.
Rack height range from 1800 to 2200 mm for multiple infrastructure layouts
Depth options from 350 to 600 mm depending on project configuration
Two width variants and modular combinations for scalable deployment
Material options include aluminium, steel or combined aluminium-steel design
Load capacity depends on selected rack type and internal equipment configuration
Cooling concept designed for fast and effective heat dissipation in active telecom and data environments
Suitable IP protection concept for datacenter and communication infrastructure applications
Mechanical robustness and precise construction for long-term equipment protection
High-quality powder-coated finishing improves durability and visual consistency
Optional shelves and internal accessory elements in aluminium and steel versions
Available internal plastic guides and lacquered components for organized cable handling
Complete internal equipment and mounting accessory preparation available on request
Customer-specific structural and design adaptations for specialized projects
Supports custom production for internal electrical and communication equipment integration
Datacenters and server infrastructure
Telecommunication distribution systems and communication nodes
5G mobile network infrastructure and edge technology hubs
Communication centers requiring scalable rack deployment
Projects that need flexible configuration, low assembly complexity and efficient internal organization
Technical snapshot
Key dimensions, benefits and compliance
DATACON is positioned as a flexible rack platform with strong customization potential, simplified installation workflow and suitable compliance for telecom and datacenter environments.
Key technical parameters
Height: 1800 – 2200 mm
Depth: 350 – 600 mm
Width: two rack variants, modular combinations
Load capacity: according to rack type and configuration
IP protection: suitable for datacenter use, project dependent
Cooling: optimized for quick and efficient heat dissipation
Key customer benefits
Modular and scalable rack system for evolving infrastructure requirements
Fast and simple installation reducing deployment effort
Combination of aluminium and steel for performance and structural balance
Premium surface finishing with powder coating
No need for unnecessarily complex cooling systems in many configurations
Single-vendor solution with lower logistics and delivery complexity
Standards and variants
IEC 60297 for rack mechanical construction
IEC 60529 for IP protection
ISO 9001 quality management system
RoHS / REACH according to configuration
Available in narrow and wide product versions
Supports customer-specific design and construction solutions
